- CSP-400 is a converter for serial to parallel ATA translation. It includes the Serial ATA PHY, Link, Transport, and Parallel ATA (application layer) controller. The Serial ATA physical, link, and transport layers are compliant to Serial ATA 1.0 CSP400 converter supports a 1.5GHz data rate. The application layer supports both the ATA register command set and PACKET command set, which could drive Serial ATA Hard Disk Drive Storage such as CR-ROM, CD-RW, DVD-ROM, DVD-RW, etc. The Parallel ATA application layer support host .
- CSP-400-330 with Master / Slave select switch
- Dimension : 100 * 25 * 15 (mm)
- Weight : 45g
- With LED Indicated power
- Easy install & free driver
- Chipset : Marvell 8040B Device mode: Master only
- Chipset : J-MICON20330 Device mode: Master /Slave
- Serial ATA 1.0 Specification compliant
- Automatic Serial ATA 1.5 Gbps speed negotiation
- ATA / ATAPI PIO mode 0 to 4
- ATA / ATAPI Ultra DMA of transfer rate 16.7, 25, 33, 48, 66, 100, 133, and 150MB/s.
- ATA / ATAPI LBA48 addressing mode associated with 2-byte sector count
- Ultra low power consumption
- Provide specified OOB signal detection and transmission
- Support Spread Spectrum Clocking to reduce EMI
- Support Partial/Slumber power management
- Provide adjustable TX signal amplitude and pre-emphasis level
